Embedded Module TQMLX2160A Embedded Cortex®-A72 module based on LX2160A with enhanced data and networking performance.
Embedded Module TQMLX2160A Embedded Cortex®-A72 module based on LX2160A with enhanced data and networking performance.
- 10G/100G Ethernet
- Highspeed communication via 24x SerDes lanes
- 2x DDR4 with ECC Support
- 100Gb/s Data Compression Engine
- 2x CAN FD, 2x USB 3.0, PCIe Gen4
- Integrated security functions
The TQMLX2160A relies on the NXP processor family Arm® Layerscape LX2160A. Depending on the required functionality, there is a choice of three CPU variants with either 8, 12 or 16 Cortex-A72. The pin-compatible CPUs (LX2160AA, LX2120 and LX2080A) with a clock rate of up to 2.2 GHz differ only in the number of cores.
For fast data communication, the compact dimensions of 126 x 78 mm integrate two interfaces for up to 100 Gigabit Ethernet. All 560 signal pins are available.
For fast data communication, the compact dimensions of 126 x 78 mm integrate two interfaces for up to 100 Gigabit Ethernet. All 560 signal pins are available.
In addition to 24x SerDes lanes with up to 25 GHz, which can be used as Ethernet, SATA and PCIe, the module has the following additional interfaces: up to 2x Gigabit Ethernet, 2x USB 3.0 2x CAN FD, up to 6x I²C, and 3x SPI.
The design is equipped with a DDR4 SDRAM memory with up to 64 GB with ECC support and up to 64 GB eMMC. The soldered RAM memory withstands even harsh environmental conditions. In addition, a QSPI NOR flash with up to 512 MB is used.
The design is equipped with a DDR4 SDRAM memory with up to 64 GB with ECC support and up to 64 GB eMMC. The soldered RAM memory withstands even harsh environmental conditions. In addition, a QSPI NOR flash with up to 512 MB is used.
CPU/Processor data
CPU/Processor:
- Cortex®-A72 - Up to 2,2GHz
CPU variant:
- LX2080A 8x A72
- LX2120A 12x A72
- LX2160A 16x A72
Memory
eMMC:
- Up to 64 GB
EEPROM:
- 0/64-kbit
Quad SPI NOR:
- Up to 512 MB
2x DDR4-SDRAM:
- Up to 64 GB
Communication interfaces
Ethernet:
- Up to 2x Ethernet 10/100/1000 Mbit
- Up to 2x 40/50/100 G-Ethernet
- Up to 16x 1/2.5/10/25 G-Ethernet
CAN:
- Up to 2x CAN FD
USB:
- Up to 2x USB 3.0 OTG interface
Serial Ports:
- Up to 2x UART
Other interfaces
SPI:
- Up to 3x SPI
- Up to 1x QSPI (8-bit)
GPIO:
- Up to 32x GPIO
SATA:
- Up to 4x SATA 3.0
SD Card:
- Up to 2x SDIO/eMMC
I2C:
- Up to 6x I2C
PCIe:
- Up to 6x PCIe Gen3 (up to 24 lanes)
Debug:
- JTAG
Other functions
RTC:
- Real Time Clock (RTC)
General data/basic data
Power supply:
- 5 V
Temperature range:
- Standard temperature range: -25°C…+85°C
- Extended temperature: -40°C…+85°C
Plug-in System:
- Board-to-board plug-in system 560 pins 0.5 mm Pitch
General:
- Temperature sensor
- Voltage Monitoring
Dimensions:
- 126 mm x 78 mm
OS-Support
OS Support:
- Linux
- on request: VxWorks
Download Subscription
With the free download subscription, registered users receive automatic e-mail notifications as soon as there are new downloads for this TQ product. How-to-guide
TQMLX2160A-AA
TQMLX2160A-AA, 16 Cortex®-A72/2.2 GHz, 8 GB eMMC Flash, 128 MB QSPI NOR, 32 GB DDR4, + ECC, 64 kB EEPROM, RTC, -40°C...+85°C
TQMLX2120A-AA
TQMLX2120A-AA, 12 Cortex®-A72/2.2 GHz, 8 GB eMMC Flash, 128 MB QSPI NOR, 32 GB DDR4, + ECC, 64 kB EEPROM, RTC, -40°C...+85°C
TQMLX2080A-AA
TQMLX2080A-AA, 8 Cortex®-A72/2.2 GHz, 8 GB eMMC Flash, 128 MB QSPI NOR, 32 GB DDR4, + ECC, 64 kB EEPROM, RTC, -40°C...+85°C, Other configurations on request
STKLX2160A-AA
STKLX2160A (Eval Kit) with TQMLX2160A-AA, 16x Cortex®-A72/2.2 GHz, 32 GB DDR4, + ECC, 8 GB eMMC Flash, 64 kB EEPROM, RTC, 2x CAN FD separated, 2x USB 3.0 HOST, 10x ETH 10/100/1000, 2x 10 Gbit Ethernet, 1x 100 Gbit Ethernet, 2x PCIe Gen4 (x4), 1x Mini PCIe + SIM Card, 1x M.2 SATA, 1x SATA 2.5”, 1x SD-Card, Temperature sensor, Reset-Button, Power Supply, 8 GB SD Card, Cables, Heatspreader, Heatsink
